ON-BOARD CLAMP OGC

Clamp

Compact cables clamps applicable to automated mounting on PC board.

Feature

Supporting wire harness on PC board.

Side and top insertion types are available.
Automated mounting and reflow soldering onPC board are applicable without boring.
Wiring on PC board edges is available which brings space saving of equipment design.

Complied with RoHS Directive 2011/65/EU
